Mindray DP-6600 Portable Ultrasound


SKU: MDP-660 Category: Tag:

Mindray DP-6600 Portable Ultrasound

The Mindray DP-6600 Portable Ultrasound is a great option for anyone looking for an affordable portable ultrasound machine that can still produce superior imaging results. This model, which weighs only 24 pounds, has a 10-inch display screen, built-in image storage, a digital beamformer and tissue specific imaging.

This ultrasound machine is a versatile and affordable black and white imaging solution in a portable package. It uses cutting-edge technology, design optimization, and ergonomics to provide the highest quality imaging for an accurate diagnosis. And at 25 pounds, you’re not limited by geography; this portable system goes wherever you go. The DP-6600 functions in both B-mode and M-mode with a variety of scanning angles and depths. The standard configuration includes two transducer connections with a frequency range of 2.0 to 10 MHz. The Mindray DP-6600 Ultrasound Machine is useful for abdominal, MSK, OB/GYN, pediatric, small parts, and urology.

Mindray DP-6600 Portable Ultrasound Features

  • Tissue Specific Imaging
  • 10-inch non interlaced monitor
  • Digital beamformer
  • Two probe connectors
  • Multi-language function
  • Built in storage for 90 images
  • 256-frame CINE loop
  • Frequency up to 10MHZ
  • Hand-held Portability
  • Multi-frequency Transducers
  • Dual Transducer Ports
  • 10 MHz microanatomy imaging
  • 16-frame image storage
  • USB 2.0 and DICOM 3.0

Mindray DP-6600 Portable Ultrasound Applications

  • Urology
  • Small Parts
  • Portable
  • Pediatrics
  • Orthopedics
  • OB/GYN
  • Abdominal

Mindray DP-6600 Portable Ultrasound Compatible Transducers

  • 35C50EA – Convex Array Transducer
  • 75L38EA – Linear Array Transducer
  • 75L60EA – Linear Array Transducer
  • 65EC10EA – Endocavity Transducer
  • 35C20EA – Micro-convex Array Transducer
  • 65C15EA – Micro-convex Array Transducer

Mindray DP-6600 Portable Ultrasound Image Processing

  • PRE-Processing
    • Dynamic Range
    • Edge Enhancement
    • Frame Correlation
    • Smooth
    • Line Correlation
    • AGC
    • 6-segment TGC adjustment
    • IP – Image Process
  • POST-processing
    • Gray Map
    • r-correction
    • Rejection
    • Left-Right Reverse
    • Up-Down Revers

Mindray DP-6600 Portable Ultrasound Specifications

  • Peripheral Ports
    • (2) Video OUT
    • (2) USB
    • (1) DICOM 3.0 – optional
  • Electrical Info: 100 – 240 VAC | 50 – 60 Hz
  • Dimensions: 11 1/4″ W x 15″ L x 12″ H
  • Weight: 24 lbs

Cart Available Upon Request (Additional charges may apply on shipping cost)
