Candela GentleMax Pro

$79,995.00

Quantity:
SKU: CAN-MAXPRO Categories: ,

Candela GentleMax Pro

The Pro Advantage: Speed, Efficacy and Versatility
Designed to deliver high performance treatment capabilities, the GentleMax Pro integrated aesthetic platform
offers more speed, power and treatment versatility than any other multi-wavelength laser system.

The Ultimate Workstation
GentleMax Pro combines the market’s fastest and most powerful 755 nm Alexandrite laser with an equally
powerful 1064nm Nd:YAG laser to deliver a range of high efficacy treatments from hair removal for all skin types
to the treatment of benign pigmented and vascular lesions including leg veins.

NEW! A 20/22/24 mm Large Spot Delivery System makes the GentleMax Pro the fastest dual wavelength hair
removal laser in the market.

There may be other multiple-wavelength systems
on the market, but none come close to offering the
enhanced speed, efficacy and versatility of GentleMax
Pro. When compared to the competition, it’s easy to
see the difference.

Advanced User Interface
Easily select the ideal settings and save treatment
parameters with the improved touchscreen interface.
The GentleMax Pro Guided Mode walks the user
through the set-up process with a series of questions
to help determine the optimal parameter settings
based on individual patient criteria.

Choice of Epidermal Protection
With GentleMAX Pro you have a choice
of skin cooling options—from chilled air
technology and our exclusive Air Cooling Compatible
(ACC) handpiece to the integrated and patented
Dynamic Cooling Device™ (DCD™) that utilizes bursts
of cryogen before and after the laser pulse to offer
unparalleled patient comfort.

System Specifications

Laser Type:               Nd:Yag                Alexandrite

Wavelength:             1064nm                   755nm

Repetition:              Up to 10Hz             Up to 10Hz

Max Energy:            80 joules (J)            53 joules (J)

Pulse Dur.:                              0.250-100ms

Spot Size:        6mm, 8mm, 10mm, 12mm, 15mm, 18mm

SDS Options:   1.5mm, 3mm, 3x 10mm, 20mm, 22mm, 24mm

Beam Delivery:   Lens-coupled optical fiber with handpiece

Pulse Control:   Finger Switch, Pulse Switch

Dimensions:     107 cm H x 46 cm W x 69 cm D (42” x 18” x 27”) 118 kg (260 lbs)

Electrical:      200-240 VAC, 50/60 Hz, 30A, 4600 VA single phase

Alexandrite Fluence

Spot Size (mm)          Fluence (0.25 ms to 100 ms)
3                                 40 to 400 J/cm2
3 x 10                            10 to 200 J/cm2
6                                  6 to 150 J/cm2
8                                  6 to 100 J/cm2
10                                 6 to 60 J/cm2
12                               10 to 40 J/cm2
15                                 7 to 30 J/cm2
18                                 6 to 20 J/cm2
20                                 5 to 16 J/cm2
22                                 4 to 13 J/cm2
24                                 3 to 11 J/cm2

Nd:YAG Fluence

Spot Size (mm)             Fluence (0.25 ms to 100 ms)
1.5                              300 to 520 J/cm2
3                                130 to 400 J/cm2
3 x 10                             80 to 300 J/cm2
6                                   6 to 200 J/cm2
8                                   6 to 150 J/cm2
10                                   6 to 100 J/cm2
12                                 10 to 70 J/cm2
15                                   7 to 44 J/cm2
18                                   6 to 30 J/cm2
20                                   5 to 24 J/cm2
22                                   4 to 20 J/cm2
24                                   3 to 16 J/cm
