Casmed CAS-740 Vital Signs Monitor

Casmed CAS-740 Vital Signs Monitor

The Casmed CAS-740 Vital Signs Monitor offers proprietary Motion Artifact Extraction (MAXNIBP®) technology provides quick accurate blood pressure readings for neonates through adults, as well as the most challenging situations like high motion or low perfusion.

Casmed CAS-740 Vital Signs Monitor Features

• Easy-to-use, reliable, accurate
• Multi-parameter capabilities
• Fast, accurate blood pressure readings for neonates through adults
• Reduces the problems of motion in blood pressure measurement
• Monitor oximetry and temperature either continuously or in a “spot-check” mode
• Covidien FasTemp Technology gives accurate oral temperature in exactly 4 seconds
• Ideal for
  • medical or surgical patients on pain medications including PCA pumps
  • hospitals
  • office-based endoscopy procedures
  • EMS market
• Casmed’s proprietary MAXNIBP technology
• Oximetry choices include
  • Masimo SET
  • Nellcor OxiMax
  • Nonin
• Created with emergency medical responders in mind
• Wireless Infrared printer option
• (3) Power Options
  • NiMH battery pack
  • internal power supply
  • DC power option
• Temperature module features Fever / Hypothermic Modes
• (4) models available
  • CAS 740-1: MAXNIBP
  • CAS 740-2: MAXNIBP and SPO2
  • CAS 740-2T: MAXNIBP and Temperature
  • CAS 740-3: MAXNIBP, SPO2 and Temperature

Casmed CAS-740 Vital Signs Monitor Specifications

PHYSICAL PARAMETERS

• Dimensions: 8-1/2″ W x 3″ D x 6-3/4″ H
• Weight: 3 lbs

NIBP

• Technique: Oscillometric MAXNIBP Technology
• Patient Range: Adult – Neonate
• Measurement Range
  • Systolic: 30 – 255 mmHg
  • Diastolic: 15 – 220 mmHg
  • MAP: 20 – 235 mmHg
• Pulse Rate Range: 30 – 240 BPM
• Accuracy
  • Blood pressure: ±5 mmHg standard deviation no greater than 8 mmHg
  • Pulse Rate: ±2% or ±2 BPM, whichever is greater

OPERATING MODES

• History: Review of previous measurements
• NIBP: Manual, STAT or Automatic
• %SPO2: Continuous Monitoring
• Temperature: Predictive or Direct

CONTROL PANEL

• Display: LED display of measurement results, instructions, troubleshooting messages, and signal strength bar
• Parameters Displayed: Systolic Pressure, Diastolic Pressure, Mean Arterial Pressure (MAP), Pulse Rate, %SPO2, Temperature °C / °F

PATIENT ALARMS

• Adjustable high and low alarms for Pulse Rate, SPO2, Systolic Pressure, Diastolic Pressure and Mean Arterial Pressure

POWER

• Source: External line or internal battery
• AC power: 100 – 240 VAC | 50 – 60 Hz | 0.5 A
• Fuse rating: T1.25A L250V
• DC Power: 12 – 30 VDC
• Battery: NiMH removable pack
• Charging time: 4 hours
• Operating time: minimum 4 hours of continuous operation
• Leakage current: 100 µA
